UV-7504PC,UV-7504C,UV-7504
UV-Vis Spectrophotometer
Introduction:
UV7504 series is single beam spectrophotometer that analyzes specimen materials in the ultra-violet and visible spectral range. Its high precision and reliable performance made it ideal for applications in medicine, petrochemistry, agriculture, food industry, biochemistry, environmental protection and many other fields.
Features:
※ Easy operation: Built-in microcomputer, pannel with simple keys, LCD display and spacious sample compartment.
※ High precision and working stability: The high reliability is achieved with the installation of a CT monochromater.
※ Advanced calculation and high automation: New micro-processing technology is applied to strengthen the data processing.
※ Automatic 0%(T) and 100%T calibration
※ Automatic interchange of wavelength and auto position adjustment of UV and Vis lamp.
※ *Compatibility with PC and printer: Built-in RS-232 interface permits data transfer to a PC. And a printer can be connected directly to the instrument through
the parallel printer port.
※ *Easy creating and storing programme and scans: With the bundled software this product is capable of charting and storing the scan results.
(*available with PC model.)
Optional Accessories
※ 100mm cuvette rack
※ Homoiothermy waterbath 3-cuvette rack
※ Universal type Test tube(Can use the Φ8~Φ16mm or Φ16mm~Φ22mm Test tube)
※ Automatic 4-cuvettes rack(1cm)
※ Reflection attachment
Specifications
| Model | UV-7504PC | UV-7504C | UV-7504 | ||||
| (Spectral scanning) | |||||||
| Optical system | Single beam, Grating 1200 line/mm | ||||||
| Spectral Bandwidth | 4nm | ||||||
| Wavelength range | 200-1000nm | ||||||
| Wavelength accuracy | ±0.5nm | ±1nm | ±2nm | ||||
| Wavelength reproducibility | 0.2nm | 0.5nm | 1nm | ||||
| Wavelength readability | 0.1nm | ||||||
| Photometric accuracy | ±0.5%T | ||||||
| Photometric reproducibility | ≤0.2%T | ||||||
| Stray light | ≤0.3%T | ≤0.5%T | |||||
| Λ220nm﹑340nm | Λ220nm﹑340nm | ||||||
| Baseline flatness | ±0.004A | / | |||||
| Stability | ≤0.004A/60min/500nm(after 30min warmup) | ||||||
| Photometric range | 0-125%T、-0.097-2.70A、0-1999C | ||||||
| Light source | Deuterium & Tungsten-halogen lamp | ||||||
| Display | LCD（2*20） | ||||||
| Data output | RS-232C | ||||||
| Analysis software | With | Support | |||||
| Detector | Silicon photovoltaic cells | ||||||
| Cuvette holder | 10mm | ||||||
| Cuvettes | 10mm quartz cuvettes /2 cases﹑10mm glass cuvettes /4 cases | ||||||
| Power | AC 100∕240V; 50∕60Hz; 300W | ||||||
| Dimensions | 440*370*200mm | ||||||
| Weight | 17kg | ||||||
