Yaxin-1162

Chl-fluorescence Analyzer

Application

1. Measurement
●     Acquisition of fast fluorescence dynamic curve OJIP (1 – 10 s).
●     Basic parameters of measuring: Fo,Fj,Fi,Fm(Fp).
2. Display of computation
●     Display of Fo,Fj,Fi,Fm(Fp) measures.
●     Display of computation for Fv, Fv/Fm etc..
●     Display of fast fluorescence dynamic curve OJIP.
●     Optional display of Chinese/English version, easy to shift.
●     Display of battery voltage, version of firmware, data store, and etc..
3. Set-up
● Set-up of file name.
● Set-up of measure for parameter collection.
● Quick selection of set-up for parameter collection.
4. Data Process
● Store: Large capacity of store for saving lots of collected data.
● Deletion: Data may be deleted when they are transmitted to a computer.
● Data transmission: Data may be transmitted to a computer with USB2.0 connection.
5. Operation aid
● Concise instruction may display for operation help.
6. Upgrade by yourself
● Safe and easy upgrade and update of software by users.

Specification

1.     Light source: LED Blue light 470nm.
Range of light intensity: 0 ~ 4000μmol/m2.s
adjustable intensity and period.
2.     Rate of sampling: once per 5μs.
3.     Store: 9999 items of intact OJIP curves.
4.     Display: 128×64 Dot matrix, Liquid crystal.
5.     Power supply: Rechargeable lithium battery 8.4V  2Ah with A.C./D.C. adapter.
6.     Weight: 800 g.
7.     Volume: 25×9×5cm
8.     Leaf clap: Suitable foe most leaves of diversity, optional clap of greater depth for larger leaves.
