KD-3390

Intelligence sensing Semi-automated Rotary Microtome

Features:

 This model utilizes a human oriented design, easy to switch between cutting and trimming, advanced technology, and stable performance, and is user-friendly;

 Specimen feeding drive utilizes an intelligent control system, it has three modes: Conventional mode , Intelligence sensing mode and whole layer cutting mode;

 Advanced drive systems including multiple functions, sectioning, trimming, fast forward, fast backward and quick conversion;

 Uses imported cross-roller guide rails and a screw motion mechanism to ensure precision resulting in superior sectioning performance;

 OLED screen shows section and trimming thickness, as well as number of sections;

 With a safety and emergency braking system, security alarm system, driver overload protection, auto-sleep protection system;

 Easy and fast switching between different specimen clamps (two options: paraffin block clamp and cassette clamp);

 Hand-wheel balance is precisely adjusted and can be locked at any position to ensure the safety of the slicing operation;

 Blade holder can be laterally moved to avoid moving the blade with direct contact, thereby utilizing the entire length of the blade (three different segments);

 The red bar on the blade holder covers the whole length of blade to protect the user and the push bar enables easy change of the blade;

 Hand-wheel balance is precisely adjusted and can be locked at any position to ensure the safety and convenience of sectioning;

 Large-volume waste tray is easy to remove and clean, and items such as deposable blades can be stored on the top of the housing.



Technical Specifications:

Section Thickness Setting Range:

0.25 - 100μm

0.25 – 2.5μm       increment 0.25μm

2.5 – 5μm         increment 0.5μm

5.0 – 10μm        increment 1μm

10 – 30μm         increment 2μm

30 – 60μm         increment 5μm

60 – 100μm        increment 10μm



Trimming Thickness Setting Range:

1 – 600μm

1 - 10μm          increment 1μm

10 - 20μm         increment 2μm

20 - 50μm         increment 5μm

50 - 150μm        increment 10μm

150 - 600μm       increment 50μm

Retraction Setting Range:

0—50μm  ( 0 is off )

5-10-15—50 (optional)

Whole layer clearance distance Range:

10 – 6000μm

10-12-15-20-25~5000~6000μm

  •  Total Horizontal Specimen Feed: 25mm
  •  Vertical Specimen Stroke: 70mm
  •  Specimen Clamp Rotation: at any angle within 360 degrees.
  •  Specimen Orientation: XY – 8°
  •  Minimum Setting of Sectioning Thickness: 0.25μm
  •  Maximum Specimen Size:70×70mm
  •  Feed speed adjust: 1500μm/s ~ 3500μm/s
  •  Precision Error:±1%
  •  Working Voltage: AC 220V±10% 50Hz (standard model) / AC110V±10% 60HZ
  •  Power:100W
  •  Dimensions:575×420×330 mm (W×D×H)
  •  Net weight:37kg
