D1536 / D1536R
High Speed Multi-Purpose Centrifuge & Refrigerated Centrifuge
Feature
Speed range from 300rpm to 15000rpm
Maximum capacity of the centrifuge: 100mLx4
Powerful cooling system for precise temperature control for both chamber and samples (1536R)
9 Acceleration/10 Brake speed settings to ensure optimal separation
A wide range of accessories
Automatic rotor identification
Timers can be set up to 99min. for short run/continuous run
Extremely quiet with low vibration levels during operation
9 procedures stored in memory makes the operation much simplified.
Specifications
| Model | D1536 | D1536R |
| Speed range | 300~15000rpm | 300~15000rpm |
| Max. RCF | 25150xg | 25150xg |
| Speed accuracy | ±20rpm | ±20rpm |
| Temperature Range | - | -20~40°C |
| Rotor Capacity | 9 types | 9 types |
| Run Time | 30sec-99mins/continue | 30sec-99mins/continue |
| Motor | Brushless DC | Brushless DC |
| Display | LCD | LCD |
| Program Memory | 9 | 9 |
| Safety Devices |
door,imb, motor over hot, speed over, chamber over temper |
door,imb, motor over hot, speed over, chamber over temper |
| Acceleration/Braking time | 9s↑/10s↓ | 9s↑/10s↓ |
| Power |
Single-phase AC220V-240V, 50Hz/60Hz, 6.3A; AC110V-120V,50Hz/60Hz,10A |
Single-phase AC220V-240V, 50Hz/60Hz, 12.5A; AC110V-120V,50Hz/60Hz,15A |
| Dimensions[WxDxH] | 445x579x269mm | 630x579x269mm |
| Weight | 36kg | 50kg |
| Certification | CE cTÜVus FCC MCA | CE cTÜVus FCC MCA |
| Advanced Features |
speed/rcf switch; rotor identification |
speed/rcf switch; rotor identification |
Available rotors
S4-100
S4-100
for D1536 & D1536R
Max. speed :4000rpm
Max. RCF:2830×g
Rotor capacity:100mL×4
Rotor material:stainless steel body and adaptor
Bio-safe(Bio sealing):YES
AS6-50V
AS6-50V
for D1536 & D1536R
Max. speed :12500rpm
Max. RCF:18690×g
Rotor capacity:50mL×6(culture tube)
Rotor material:aluminum
Bio-safe(Bio sealing):YES
AS12-PCR8
.jpg)
AS12-PCR8
for D1536 & D1536R
Max. speed :14000rpm
Max. RCF:21910×g
Rotor capacity:PCR 8 trips×12
Rotor material:aluminum
Bio-safe(Bio sealing):YES
AS30-2(Default)
_%e5%89%af%e6%9c%ac03.jpg)
AS30-2(Default)
for D1536 & D1536R
Max. speed :15000rpm
Max. RCF:25150×g
Rotor capacity:2mL×30
Rotor material:aluminum
Bio-safe(Bio sealing):YES
AS60-2
AS60-2
for D1536 & D1536R
Max. speed :14000rpm
Max. RCF:21910×g
Rotor capacity:2mL×60
Rotor material:aluminum
Bio-safe(Bio sealing):YES
AS18-5V
.jpg)
AS18-5V
for D1536 & D1536R
Max. speed : 15000rpm
Max. RCF: 25150xg
Rotor capacity: 5mlx18(culture tube)
Rotor material:stainless steel body and aluminum buckets
A8-50
A8-50
for D1536 & D1536R
Max. speed : 5000rpm
Max. RCF: 3460xg
Rotor capacity: 50mlx8 or 15mlx16
Rotor material:aluminum body and stainless steel adaptor
S2-MP
S2-MP
for D1536 & D1536R
Max. speed :4000rpm
Max. RCF:2200×g
Rotor capacity:Micro-plants 384-PCR; 96-PCR
Rotor material:stainless steel body and aluminum buckets
A30-15
A30-15
for D1536 & D1536R
Max. speed :4000rpm
Max. RCF:2110×g
Rotor capacity:15mL×30
Rotor material:aluminum body and stainless steel adaptor
