Center 45D / Center 60D / Center 90D
Center series Deionized water system (tap water inlet)
Features and Advantages
1.System circulation function, achieve ultrapure water’s circulation to keep top quality of ultrapure water.
2.All Cartridges replacing alarm function, based on time, or water quality, show cartridges’ used and residual life.
3.Multiple alarm function: no feed water, full water, water quality’s standard exceeding, and cartridge life ending.
4.Auto self-flflushing of RO membrane function (interval and continuous time setting), extend RO membrane’s life.
5.Comprehensive Information query and management function, master system status, water quality, cartridges usage and alarm information.
6.System time setting (year/month/day/hour/minute), timing standby (0-60 minute), and timing shutdown (0-24 hour) function.
7.Level II password, protect all the parameters setting, and prohibit any unauthorized setting change.
8.Built-in 20 liters PE tank and 20 liters airtight plastic pressure water tank. Also external tanks is optional.
9.3 door and easy-to-replacing cartridge design, convenient to maintain system and replace cartridges.
10.Detachable water collector design, store water-drop to avoid water’s splashing, and convenient for cleaning.
11.Tube and adapter with NSF authorization and top quality, reduce TOC level and assure ultrapure water’s quality.
12.Optimized pretreatment (including PP fifiber, KDF and active carbon cartridge), effectively protect RO membrane.
13.RO module with DOW’s membrane, ensure long life, stable operation and high desalinization rate.
14.Ultrapure cartridge with DOW’s top polishing resin, ensure ultrapure water’s quality up to 18.2 MΩ.cm, with the lowest TOC level.
15.Double wavelength (185&254nm) ultraviolet lamp module, restrain bacteria’s increase and reduce TOC.
16.MWCO 5000D ultrafifiltration module, effectively eliminate endotoxin, and suitable for precise cell cultivating and IVF.
17.0.2µm high flflux PES terminal disinfection fifilter, assure that terminal pure water is absolutely axenic.
18.System sanitizing procedure, achieve the disinfection of ultrapure water’s tube and valve.
Flow Schematic
Specification
