ZWY-1102C/2102C/1102//2102/1112B/2112B, ZWF-1112/2112
恒温摇床
Descriptions:
These double layer shaking incubators are specially developed for the modern biological engineering departments; a big capacity of flasks but with small footprint. The units are widely used in germ culture, hybridization, biochemical research, enzyme and cellular tissues. All of these tests require high temperature performance and stabile oscillation frequency.
These incubators have a smooth compact design. They are very efficient and have an excellent floor space/performance factor. Two trays above each other, double the capacity for smaller flasks, while after removing the top tray, big flasks can also be used on the bottom tray. These unit are particularly ideal for fermentation and pharmacy experiments. While they are also widely used where a big amount of liquid needed to be mixed on a constant temperature.
Features:
Microprocessor controller with audible and visual alarms maintains precise temperature and speed control.
CFC-free refrigerant causes no damage to ozone layer.(Only applies on models with cooling capacity).
Users friendly control panel allows easy digital setting of time, temperature and speed.
Large LCD display presents all actual and (pre)set parameters.
Electronic timer, from 0 – 500 hours, automatic stop, audio/ visual alarm.
Password protection against unauthorized change of parameters.
Audible and visual alarms for over-temperature and set point deviations.
Non-volatile memory for set point retention after a power interruption.
Large double-fold tempered glass window, together with fluorescent lights provides complete visibility of chamber interior.
“Long-Life” brushless AC motor creates a smooth, quiet and uniformed shaking motion.
Mirror-finished high quality #304 stainless steel for excellent durability of interiors.
Standard shaking frame and standard stainless steel tray included (without clamps).
Vertical double trays for big capacity, though small footprint.
Lockable outer door (Applicable on ZWY-1112B/2222, ZWF-1112/2112) protects the materials against unauthorized access at all times.
Specification
| Model |
ZWY- 1102C |
ZWY- 2102C |
ZWY- 1102 |
ZWY- 2102 |
ZWY- 1112B |
ZWY- 2112B |
ZWF- 1112 |
ZWF- 2112 |
| Volume (L) | 170 | 330 | 580 | 580 | ||||
| Shaking Mode | Orbital | Orbital | Orbital | Reciprocal | ||||
| Temperature (°C) | A +5 to 60 | 4 to 60 | A +5 to 60 | 4 to 60 | A +5 to 60 | 4 to 60 | A +5 to 60 | 4 to 60 |
| Temperature Accuracy | ±0.1℃ | |||||||
| Temperature Uniformity | ≤±1℃@37℃ | |||||||
| Stroke (mm) | 26 | 26 | 35 | 1 to 50 Stepless djustment | ||||
| Speed (rpm) | 30-300 | 30-300 | 30-300 | 30-240 | ||||
| Tray (mm) (WxD) | 496x350 | 734x458 | 970x560 | 940x580 | ||||
| Capacity | *Glass dimensions may reduce max. capacity | |||||||
| 50 ml | 56 | 104 | 164 | 164 | ||||
| 100 ml | 56 | 104 | 164 | 164 | ||||
| 250 ml | 28 | 56 | 90 | 90 | ||||
| 500 ml | 22 | 44 | 74 | 76 | ||||
| 750 ml | 18 | 30 | 52 | 48 | ||||
| 1000 ml | - | 24 | 36 | 44 | ||||
|
Inner dimensions (mm) (WxDxH) |
615x440x640 | 845x515x765 | 1105x665x775 | 1105x665x775 | ||||
|
Exterior dimensions (mm) (WxDxH) |
720x630x1275 | 950x710x1370 | 1430x800x1660 | 1430x800x1660 | ||||
|
Packing dimensions (mm) (WxDxH) |
840x750x1445 | 1070x830x1540 | 1550x920x1830 | 1550x920x1830 | ||||
| Net/Gross Weight (kg) | 150/175 | 165/190 | 225/265 | 239/272 | ||||
| Power (W) | 1000 | 1250 | 1050 | 1300 | 1600 | 1950 | 1600 | 1950 |
| Electricity | 220-240V 50/60 Hz | |||||||
| Approval | CE, ISO | |||||||
