JS-II
GELATIN GEL STRENGTH TEST SYSTEM
Gel strength test system is mainly used to measure the gel strength of gelatin under the stipulated environment. The gel strength of gelatin is an important indicator to reflect the technological level of gelatin production and control the production quality of gelatin.
System composition：◎ 1 set of JS-Ⅱ gel strength tester host ◎1 set of HW-Ⅲ precise constant temperature monitoring cold water tank ◎1 set of ZL-Ⅲ efficient refrigerating machine
Applicable standards：
◆National standard Food Additive Gelatin GB6783
◆National standard Hard Capsule of Pharmaceutical Gelatin GB13731
◆Industrial standard Pharmaceutical Gelatin QB2354
◆Industrial standard Industrial Gelatin QB/T1995
◆Industrial standard Bone Gelatin QB/1996
◆Industrial standard Photographic Gelatin QB1997
Host of gel strength tester
Technical indexes：
◇Meet the requirement for measurement time limit in Pharmacopoeia of Edition 2015
◇Computer monitors the press-in depth error of probe to the gelatin surface dynamically.
◇Intelligent LCD
◇Test range：5-1000Bloomg
◇Test precision：±0.3%
◇Resolution： 1g
◇Repeated measurement error：±1 Bloomg
◇Sampling depth：1-60mm
◇Stroke error：≤±0.1mm
◇Stroke error of high-speed measurement：≤±0.1mm
◇Measured value：take Bioom g as the unit
◇Measured diameter of cylinder：12.700±0.010mm
◇Standard gel strength bottle： volume=150ml; inner diameter=59mm; height=85mm
◇Total power：60W
◇Overall dimensions：L*W*H 260mm*260mm*450mm
Main features of host of gel strength tester：
◎Intelligent professional model which can meet various complicated measurement requirements of professional staff.
◎High-definition LCD is adopted, users can enjoy intelligent operations according to the screen tips; Chinese character and quantitative index are provided for each operational process.
◎ Powerful data processing ability; it can submit the parameters like mean value, final value or peak value of tested gelatin sample for you automatically.
◎It provides four kinds of sampling measurement modes including single-step, maintaining, circulating and automatic, making you operate with higher proficiency.
◎Automatic measurement mode can help you obtain the value of gel strength faster, more accurately and more realistically.
◎ The instrument provides presetting of any sampling depth, which facilitate the users to extract the data of various levels of gelatin sample.
◎ 5 kinds of sampling speeds; 0.1mm/s, 0.2mm/s, 0.5mm/s, 1mm/s and 2mm/s. High-speed measurement is chosen, the press-in depth error of probe to the gelatin surface will not occur.
◎ Sampling depth can be preset arbitrarily（1mm----60mm）.
◎ The instrument provides 2 kinds of sampling results, in cooperation with the different test combinations of sampling speed and sampling mode, so as to provide users with final value and peak value.
◎ Professional high-precision pressure sensor.
◎ High-precision mechanical drive matches with 4-class shockproof design
◎ Users can verify the measurement accuracy of instrument itself by themselves. (with standard weight)
◎ Automatic correction of non-linear error, automatic fault diagnosis alarm, automatic outrange protection and automatic error correction prompt.
Thermostatic water tank and refrigerating machine
Technical indexes:
●Water bath temperature control range （５～60．０）℃
●Water bath temperature control precision ±０．１℃
●Refrigerating time （３０℃→１０℃）＜４０ｍｉｎ
●Power supply ２２０Ｖ／５０Ｈｚ／１２００Ｗ
●Overall dimensions ＨＷ－Ⅲ （５８×４４×２２）ｃｍ３
ＺＬ－Ⅲ （４８×３８×２９）ｃｍ３
Main features:
●Thermostatic water tank and refrigerating machine constitute the precise constant temperature cold bath system.
●Magnetic water pump circulating water flow uniform heat system is adopted, and bath temperature is uniform.
●High-precision temperature sensor has small linear error and high temperature measurement accuracy.
●Full-automatic frequency converting control technology controls the temperature intelligently, with high temperature control precision.
●Refrigerating machine adopts new type compressor with high reliability and high power for refrigeration; the refrigeration speed is fast and noise is small.
●Temperature can be preset at will; the preset value and real-time value can be displayed by time division.
●Automation: automatic test, automatic diagnosis and automatic alarm.
●The liner of thermostatic water tank is made of high-quality stainless steel material, temperature control range is wide and appearance is beautiful and elegant.
Specifications:
Test range (5～1000)g
Test accuracy Max*(±0.05% )
Travel (1～60)mm
Travel accuracy ±0.1mm
Temperature control range (5～39.9)℃
Temperature control accuracy ±0.1℃
Cooling time 40min
Volume accuracy ±0.5mL
Power 220V/50Hz/1200W
Dimension JS-2 (260×260×420)mm3
HW-2 (530×450×280)mm3
ZL-2 (400×350×280)mm3
