BPN-80CRH(UV),BPN-150CRH(UV),BPN-240CRH(UV)

CO2 Incubator



With imported infrared CO2 Sensor (Professional CO2 Incubator for cell)

 Features:

1. Co2 concentration Restoration Speed

2. Polished stainless-steel chamber, semicircular arcs at corners for easy cleaning,and the space between the shelves in the chamber is adjustable.

3. Microorganism filter at inlet provides 99% filtration of bacteria and dust(Φ<0.3um) and supplies pure Co2 into the incubator.

4. Door temperature controller prevents dewfall on glass door of incubator effectively.

5. Independent audible and visible temperature-limiting alarm system ensures experiments run safely.

6. Alarm function for temperature difference, Co2 over concentration and concentration difference, door open time, UV working status.

7. Auto-controller of fan speed to prevent damage to the samples

8. Hot air sterilizing circulation system

9. UV light system for periodic sterilization of chamber(Option)

10. RS-485 Connector: easy to download and save all the data via RS-485 into computer, and identify problems in time.

11. PID controller with large LCD screen ensures precise and reliable control.



Specifications:

Model BPN-80CRH(UV) BPN-150CRH(UV) BPN-240CRH(UV)
Electrical Requirement 220V 50HZ
Power Consumption 500W 750W 950W
Heating Method Air-jacketed, PID Control
Temperature Range RT+5~55°C
Ambient Temperature RT+5~30°C
Temperature Stability ±0.1°C
CO2 Range 0~20%UV
CO2 Control Resolution  +/-0.1%(IR sensor)
CO2 Recovery (Door open 30s, recovery to 5%)<=3min
Temperature Recovery (Door open 30s, recovery to 37%)<=8min
Humidity Method Natural vaporization > 95%
Chamber Volume 80L 155L 233L
Interior Dimension 400*400*500 480*530*610 600*630*670
(W×D×H) mm
Exterior Dimension 580*500*690 670*767*880 788*837*940
(W×D×H )mm
Shelves 2pcs 3pcs 3pcs



Options

1.  humidity diplay

2. CO2 pressure releasing valve

3. RS485 connector
