SX650
Conductivity/TDS/Sal/Res Tester
Introduction
● Compared with similar products: the widest measurement scope 0~50mS/cm, more measurement parameters, ability to switch among conductivity, TDS, salinity and resistivity. multinomial calculation for TDS and salinity to ensure the conversion precision of the full scale.
● The smallest and thinnest shape: 148×29×14mm. The diameter of the electrode: 10mm.
● The best function: automatic calibration, automatic temperature compensation, automatic switch of range, automatic power off, low voltage alarm, etc.
● The easiest to use : single button operation.
● Meet IP57 waterproof rating, replaceable batteries, calibration solution and standby batteries in a portable case.
Specification
| Cond. | Range | Cond.：0~50.0μS/cm 50~500μS/cm |
| 0.50~5.00mS/cm 5.0~50.0mS/cm | ||
| TDS: 0 ~ 35.0g/L | ||
| Sal.： 0 ~ 25ppt | ||
| Res.：0 ~ 20.0MΩ·cm | ||
| Accuracy | ±1.0% FS | |
| ATC |
0 ~ 50℃（Auto.），Compensation Factor：2.0% /℃ |
|
| Auto. Calibration | 1 point（1413μS/cm） | |
| Temp. | Range | 0 ~ 50℃ |
| Resolution | 0.1℃ | |
| Accuray | ±0.5℃ | |
| Other Specifications | Power |
CR2032 lithium batteries×2，continuous use for over 100 hours |
| Dimension & Weight |
Meter：148×29×14mm / 43g Case：168×96×28mm / 180g |
|
| Quality&Safe Certificate | ISO9001:2008, CE and CMC | |
| Working Conditions | IPRating | IP57 Dustproof & Waterproof |
Standard Kit Includes
| 1. SX650 meter | 1 set |
| 2.1413 calibration solution（10ml） | 1bottle |
| 3. CR2032 batteries (spare） | 2pcs |
| 4.Portable Case | 1set |
| 5. Manual | 1copy |
Optional Accessories
| Category | Description | Specification |
| conductivity electrode | SX655 plastic conductivity electrode |
Measure regular conductivity, match SX650 pen tester. |
| Conductivity calibration solution |
84 μS/cm conductivity calibration solution |
500mL/250mL/50mL/10mL （bottle） |
|
1413 μS/cm conductivity calibration solution |
500mL/250mL/50mL/10mL （bottle） |
|
|
12.88 mS/cm conductivity calibration solution |
500mL/250mL/50mL/10mL （bottle） |
|
| Battery | CR2032 lithium battery | Match SX650 pen tester. 4 units. |
