JS-2000
Automatic Gel Imaging Analysis System
JS series of Gel Imaging Analysis System configurations
| JS-2000 Automatic Gel Imaging Analysis System |
| Name & Specification |
| JS-2000 Automatic Gel Imaging Device |
| Data-processing system |
| PQ-P510Z professional digital low illumination integrated CCD |
| Computer M6Z1212M 2/3 inches, large diameter, high permeability of lens |
| Coating filter specially designed for various fluorescent dye of gel imaging feature |
| Gel cutting devices |
| Gel Image Shooting Software |
| Gel Imaging Analysis Software |
Technical parameters
| JS-2000 Automatic Gel Imaging Analysis System | |
| Digital CCD | PQ-P510Z professional digital low illumination integrated CCD |
| Data-processing system | Intel Atom N270 1.60GHz，512kbyte L2 |
| Memory | 1 x DDR2 SODIMM 1GB （Maximum capacity 2GB） |
| Hard disk | Solid hard disk 8GB(or Solid hard disk 120GB) |
| USB | Support seven USB 2.0(three USB 2.0 need be expanded) |
| NIC | 8111C Realtek on-board double -gigabit NIC, support no disk |
| Detection Sensitivity | The detection of Nucleic acid as Low as 0.02ng |
| Effective Pixel | 1392 x 1040 |
| Lens |
Japan computer automatic zoom lens with high permeability F=1:1.2, 12.5～75mm, gel size on request free to zoom |
| Data bits | 10bit(0-1024 gray-scale) |
| Pixel size | 4.4μm x 4.4μm |
| SNR | ≥ 60dB |
| Shutter control | Electronic shutter |
| Exposure time |
Long exposure time from 4ms to 60 minutes, collect and store all images successively, possess image correction function |
| Interface | Standard C interface |
| Cutting device |
special observation and cutting devices (visual angle and the object is 90 °) |
| Color filter film |
Coating filter specially designed for various fluorescent dye of gel imaging feature ,Standard configuration of 590nm(or 535nm, 620nm, 460nm) EB/SYBR Green, BP |
| Case control |
Via case panel to realize the automatic control - zoom, focus, aperture, transmission UV lamp and reflector lamp |
| Computer control |
highly programmed (computer controlled black box / power / UV and white light switch / iris / focus / focal length) |
| Timing shutdown |
Shutdown timer for 15 minutes, effectively extending the UV lamp life and UV glass |
| The way of Opening door | pull-down to open the door and drawer-platform |
| UV transmission loading board |
Transmission wavelength: 302nm(254nm, 365nm (is optional)), size: 20cm x 25cm(special specifications can be customized) |
| White light reflection | Cooling light, voltage 12V |
|
White light transmission loading-board |
Cooling light, voltage 12V, chassis panel internal folding 20cm x 25cm (special specifications can be customized) |
| Quality authentication |
Only one of gel imaging systems passes national authoritative measurement authentication instruction, and obtains third class of Shanghai scientific advance prize |
| Shape size | L50CM X W37CM X H82CM |
| Application |
can be used for DNA / RNA gels, protein gels, blot autoradiography film plastic card, the enzyme Standard plate, thin layer chromatography plate, imaging and analysis of dish |
