HR/T20MM
Free Standing High-Speed Refrigerated centrifuge
Features:
With TFT true-color LCD wide-screen touch monitor featured by intelligent control,easy and convenient operation,a touch panel and a simultaneous indication of both the set parameters and operation ones.
Use a brushless motor with high torque and variable frequency which is controlled by an SCM of Microchip's dsPIC30F Series and driven by a special driver module of FAIRCHILD's FSBB30CH Series to ensure the circuit's reliability.
The design of the whole machine is in line with the ergonomics.with a streamline design,a complete steel structure and a stainless steel centrifuge cavity,it is safer,better looking and more efficient.
With multiple protection measures such as super speed,over heat and imbalance as well as a special combination of shock absorbers to keep the motor running smoothly.With triple protective layers of steel bushing to achieve secure and reliable operation as well as personnel and equipment safety.
Rotors at rest will be in standby and cool down.
With a dedicated key indicating the centrifugal force which has the inching function for momentary centrifugation.
With a motor gate lock mute mechanical & electrical integration.
Able to provide more than 20 kinds of operating modes for the user to programme and use freely.
10 levels for speed-up and speed-down control.
Maximum rotation speed:20600r/min,Maximum capacity:4x750ml.
Specification:
| Model | HR26M |
| Standard rotor | Swing rotor 4×750ml |
| Max Capacity | 12×1.5/2.0ml |
| Max Speed（r/min） | 20600r/min |
| Speed precision | ±50r/min |
| Max RCF（×g） | 29400×g |
| Refrigeration system | Import fluoride-free compressor and control valve（R404a） |
| Temp.control range | －20℃～40℃ |
| Temp.precision | ±1℃ |
| Temp.control range | -20℃～+40℃ |
| Temp.precision | ±1℃ |
| Operation pro grame | 20 |
| Temp.control range | Frequency motor，micro control，direct driver |
| Total power | 2kw |
| Timer range | 0-99h59min |
| Noise | ≤65dB |
| Power | AV220V 50Hz |
| weight | 110 kg |
| Dimension（L×W×H） | 710×560×770mm |
| Model | capacity | HR/T20MM | |
| Speed（r/min） | RCF(×g) | ||
| Angle rotor | 12×1.5/2.0ml | 20600 | 29400 |
| Swing rotor | 4×750ml | 4000 | 3500 |
| 4×500ml | 4000 | 3580 | |
| Adpator | 4×250ml | ||
| 4×8×15ml | |||
| 4×12×10ml | |||
| 4×3×50ml | |||
| 4×19×5ml | |||
| （vacuum tube） | |||
| 24×1.5/2.0ml | 14000 | 18180 | |
| 12×10ml | 14000 | 18800 | |
| 6×50ml | 12000 | 13800 | |
| 4×100ml | 10000 | 10500 | |
| 6×100ml | 11000 | 14520 | |
| 6×250ml | 8000 | 9200 | |
| Swing micro-plate rotor | 2×2×96 hole | 4000 |
2360 |
