EC310T
Portable Conductivity Meter
.jpg)
GENERAL FEATURES
● Color High contrast LCD touchscreen, 4.3 inches.
● Intelligent operation system provides features including user management, calibration management, electrode management, method management, data management and etc.
● Multi-reading feature allows auto-read, timed-read and continuous-read.
● Automatic/Manual temperature compensation ensures accurate results.
● Auto-hold feature senses and locks the measurement endpoint.
● Data storage 1000 sets for each parameters (GLP-compliant).
● Data analysis feature helps user review, compare and recalculate results.
● Support for USB communication.
● Auto-power off feature effectively extends the battery service life.
● Reset feature automatically resumes all settings back to factory default options.
● IP65 waterproof.
Conductivity
● 1-5 points calibration automatically recognizes the standard solutions.
● Settable parameters, including cell constant, reference temperature (5/10/15/18/20/ 25°C), temperature compensation coefficient and TDS factor.
● Temperature compensation type (none, linear, pure water).
Specification
|
Model |
EC310T |
|
|
Parameters |
EC/Temp.(Resistivity/TDS/Sal.) |
|
|
Conductivity |
Range |
0.000 μS/cm to 1000 mS/cm |
|
Resolution |
0.001 μS/cm minimum, |
|
|
various with range selection |
||
|
Accuracy |
±1.0% FS |
|
|
Reference Temperature |
20, 25 ºC |
|
|
Calibration Points |
Up to 3 |
|
|
Standard Recognition |
84μS/cm, 1413μS/cm, 12.88mS/cm |
|
|
Resistivity |
Range |
5.00 Ω ·cm~20.00 MΩ ·cm |
|
Resolution |
0.01Ω ·cm minimum, |
|
|
Accuracy |
±1.0% FS |
|
|
TDS |
Range |
0.00mg/L~300g/L |
|
Resolution |
0.01mg/L(0.001mg/L) minimum, 3 significant digits |
|
|
Accuracy |
±1.0%FS |
|
|
Salinity |
Range |
(0.00~8.00)% |
|
Resolution |
0.01% |
|
|
Accuracy |
±0.2% |
|
|
Temperature |
Range |
-5 to 110 ºC, 23 to 230 ºF |
|
Unit |
ºC, ºF |
|
|
Resolution |
0.1 |
|
|
Relative Accuracy |
±0.2 |
|
|
Measurement |
Reading Mode |
Auto Read (Fast, Medium, Slow), Timed, Continuous |
|
Reading Prompts |
Reading, Stable, Locked |
|
|
Temp. Compensation |
ATC, MTC |
|
|
Data management |
Data Storage |
1000 Groups |
|
GLP Features |
Yes |
|
|
Inputs |
Conductivity with Temp. Probe |
5-pin aviation connector |
|
Outputs |
USB |
PC, printer |
|
Display options |
Backlight |
Yes |
|
Auto Shutdown |
300, 600, 1200, 1800, 3600sec., off |
|
|
IP Rating |
IP65 |
|
|
Date and Time |
Yes |
|
|
General |
Power |
Rechargeable Lithium battery, AC Adapter, 100-240V AC input, DC5V output |
|
Dimensions |
90 x 255 x 40 mm |
|
|
Weight |
500g (1.1 lb) |
|
