BSI-21/BSI-31/BSI-21C/BSI-31C
Chest Type Shaker Incubator
Application
Floor standing Shaker incubator combines incubator and shaker functions together, it uses new outlook design with big touch screen,. Adopt the latest
technology of motor driven system, large torque, stable work, low noise and fast heat dissipation and long lifetime. It is widely used Cell culture, fermentation,
biochemistry, enzyme research experiment or medium production experiment. Especially suitable for medium production, it solves the user’s problem by
advanced design and high precise manufacturing art craft.
Product features
Colorful intelligent touch screen control
● Adopt 4.3 inches touch screen , intelligent touch screen control, parameters real time display, operation easily.
● Temp, rotation speed and time etc parameters fast setting.
Humanization design
● Combine incubator, shaker functions together with small space, huge capacity.
● Colorful touch screen controller, menu operation interface, multi data display at one screen, easily to observe and operate.
● Silent running.
● Fluorine-free design, environmental friendly.
● Big transparent big view windows, platform and chamber are made of stainless steel, anti-corrosion and easy to clean.
Quality guaranty
● User’s set parameters can be stored automatically when power off suddenly, and it resume last program settings when power on.
● PID microcomputer control temp. and shake frequency with timer.
● Compressor and cycle fan etc key components are reliable suppliers, environmental non-free refrigerants.
Uninterrupted performance guaranty
● Brushless DC motor, large start torque, wide speed adjustment, free maintenance.
Three-eccentric axis balance drive
● Three-eccentric axis balance drive ensures all samples in the shaker platform movements at the same rotation frequency.
Durable structure guarantees the shaker incubator can work properly no matter full load or high speed working.
Convenient data process
● Equip with USB as options, record temp. parameter changes (option)
● Equip with RS232 data interface, through software to remote control machine performance (option)
● Above two options can be selected only one.
Safety
● Protection on instruments: Comply international standard secondary temp. limiter alarm system, alert the operator with sound and light alarms, ensure operator is safe without any accident.
● Protection on key components: Key components have over current, over temp., over load etc safety protection, it can prevent instruments accidents without precautions.
● Protection on samples: Working chamber temperature higher or lower the set temp., alarm starter cut down the heater, alert the operator with sound and light alarms.
● Protection on operator: Cabinet and door is special designed for insulation, low heat of cabinet body, ensure operator use instrument without burnt.
● Breakdown message provided: When the instrument breakdown, the breakdown messages show on the screen to help operator easily check.
Multi-segment programmable control
● Multi-segment temp., speed, time program at the same time. It has normal mode or programmable mode for running. Preset parameter and work data can be shown at
the same time. It simplified complicated culture requirements and realize auto control and run.
Feature extension(option)
● CO2 concentration monitor and control.
● Lighting control.
● Humidity monitor and control
Technical parameters
Max. flask clips can be placed (single layer)
