SURVEY
Chromatography Data System
Overview:
SURVEY is the updated version of Clarify, which add the function of account manage-ment, program management, also accord with GMP, FDA, 21CFR requirements.
Quick Details
l Ensure the data safety on different authority users
l SST Fuctions ensure the procession reliability
l Audit Trail
l Effective Group data process
l More user defined templates
l Meet GMP, GLP, FDA, 21CFRⅡCertification
Specifications:
General
Number of Channels: 2
Input Voltage: -2.5V ~ 2.5 V
Input Resistance: > 10 MΩ
Sensitivity of Integration: 1 u V/s
Minimum resolution: 1 u V
Dynamic Range: 107
Linearity: ±0.1 %
Peak Processing
Number of peaks: > 1000
Width of peak: 0.01 s
Automatic Time Programming
Manual Integration enabled
Automatic identification of complex peaks and precise parti-tion of overlapped peak
Automatic tracing and correcting base line
Automatically eliminate the affect of negative peak
Meet the GMP regulation
Methods for Identifying Peak
Conservative time method
Components table method
Parameters for Integration
Peak area
Peak height
Method for Quantitative Calculation
1. Normalized Method,
2. Normalized Method with Proportional Factor,
3. Internal Standard Method,
4. Grouping Method,
5. Multiple Internal Standard Method,
6. External Standard Method,
7. Logarithmic Method.
Work screenshots:
1. Main window
2. User management
3. Program management
4.Audit Record
5.Config management
6.Work window
7.Spectrum processing
