Bante321
Portable Ion/mV/℃/℉ Meter
Bante321 portable ion meter can use various combination ion selective electrodes to measure concentration of sample. The meter will direct shows concentration values without data conversion requirements.
Features:
2 to 5 points push-button calibration from low to high concentrations.
Selectable multiple concentration units, including ppm, mg/L and mol/L.
Direct readout ion concentration simplifies the elaborate measurement process.
mV measurement allows user to check performance of ion electrode.
Automatic Temperature Compensation (ATC) ensures highly accurate measurements over the entire range.
Automatic endpoint function freezes the stable measured values for easy reading and recording data.
Calibration due reminder prompts you to calibrate the meter regularly.
Help message as a operational guide to helps you understand how to use meter.
Setup menu lets user customize calibration points, ion concentration units, stability conditions, temperature units, date and time to meet measurement requirements.
Reset function can resumes all settings to factory default values.
Expanded memory stores and recalls up to 500 readings.
Built-in real-time clock stamps stored data to meets GLP standards.
Stored data can be transferred into computer via USB communication interface.
Specifications:
| Model | Bante321 |
| Ion Concentration Range | 0.001~19999 (Depending on measuring range of Ion Selective Electrode) |
| Ion ConcentrationAccuracy | ±0.5% Full Scale |
| Selectable Units | ppm, mg/L, mol/L |
| Calibration Points | 2 to 5 points |
| Calibration Solutions | 0.001, 0.01, 0.1, 1, 10, 100, 1000, 10000ppm or mg/L or mol/L |
| mV Range | -1999.9~1999.9mV |
| mV Accuracy | ±0.2mV |
| Temperature Range | 0~105°C, 32~221°F |
| Temperature Accuracy | ±0.5°C, ±0.9°F |
| Temperature Calibration | Manual |
| Temperature Compensation | 0~100°C, 32~212°F, Automatic or Manual |
| Auto-Off | Manual or Automatic (10, 20, 30 minutes after last key pressed, Selectable) |
| Hold Function | Manual or Automatic |
| Stability Conditions | Low or High, Selectable |
| Calibration due reminder | 0 to 30 days |
| Reset Function | Yes |
| Memory | 500 data sets with Date/Time stamping |
| Output | USB Communication Interface |
| Connector | BNC |
| Power Requirements | 3×1.5V "AA" Batteries |
| Dimensions | 170(L)×85(W)×30(H)mm |
| Weight |
300 grams |
