YDS-10L YDS-2OL YDS-30L YDS-35L YDS-50L
LN-Only Aluminium Container
Product details
This series is designed specifically for liquid nitrogen storage, and characterised by their small calibers and low static evaporation loss.
Main Features:
1. High-strength aluminum alloy structure;
2. Multi-layer thermal isolation design;
3. Protective jacket to prevent collision;
Specifications
| Model | Unit | YDS-10L | YDS-2OL | YDS-30L | YDS-35L | YDS-50L | |
| Capacity | L | 10 | 20 | 31.5 | 35.5 | 50 | |
| Empty Weight | kg | 6.2 | 11.2 | 12.9 | 13.8 | 21.1 | |
| Neck Diameter | mm | 50 | 50 | 50 | 50 | 50 | |
| Outer Diameter | mm | 303 | 409 | 446 | 473 | 500 | |
| Height | mm | 530 | 650 | 670 | 680 | 805 | |
| Static Evaporation Loss | L/d | 0.1 | 0.1 | 0.1 | 0.11 | 0.2 | |
| Static Hold Time | d | 101 | 202 | 295 | 333 | 252 | |
| Canister Outer Diameter | mm | - | - | - | - | - | |
| Canister Height | mm | - | - | - | - | - | |
| Numbers of Canisters | ea | - | - | - | - | - | |
| Straw Holding Capacity | ea | - | - | - | - | - | |
| Optional Locking Cover | ea | - | - | - | - |
- |
|
